| Model | JDD-2000-HDX |
| Wavelength | 808±5nm |
| Laser chip | 15W |
| Illumination angle | Electric synchronous zoom,42°～0.3°continuous adjustable |
| Zoom Speed | 3S(optical, Wide-angle go to Tele-angle) |
| Effective distance | Tele-angle：Effective distance>2000m |
| Control mode | Photosensitive sensor / Command |
| Brightness setting | Auto / Manual |
| Voltage | DC24V±10% |
| Total power | 40W |
| Storage temperature | -40℃～+80℃ |
| Work temperature | -40℃～+70℃ |
| Product life | >30000hours |
| Size | LxWxH:467*101*105mm(Integrated)\349*105*103mm(Separation) |
| Weight | about2000g |
| Communication mode | TTL 3.3V/ RS485（9600bps） |
